3inch water pump 48v dc motor brushless solar power system home pump


3inch water pump 48v dc motor brushless solar power system home pump

1. Permanent magnet DC brushless synchronous motor
Controller Features:
- Automatically run when power enough or tank is not full. Automatically off when tank is full.
- High waterproof grade: IP65, double seal effect in waterproof and leak-proof
- Soft start technology: No impulse current, longer life for the pump motor.
- High voltage/Low voltage/Over-current/High temperature protection
- 1 years warranty.Â

PUMP VOLTAGE
(V)
|
SOLAT PANEL
(W)
|
PEAK VOLTAGE
VMP(V)
|
OPEN CIRCUIT VOLTAGE
VOC(V)
|
24V/36V
|
≥1.3PUMP POWER
|
≥18
|
18V-50V
|
48V
|
≥1.3PUMP POWER
|
=30
|
30V-96V
|
72V
|
≥1.3PUMP POWER
|
≥50
|
50V-150V
|
96V
|
≥1.3PUMP POWER
|
≥60
|
60V-180V
|
110V
|
≥1.3PUMP POWER
|
≥60
|
60V-180V
|
IMPORTANT: DO NOT JUDGE PUMPS BASED ON HORSE POWER!
3inch water pump 48v dc motor brushless solar power system home pump

What We Get For You (Package Include):
 – 1 x 3″ DC solar Pump with 2m cableÂ
 – 1 x  Pump controller with MPPT function
 – 1 x Stainless steel float switch (sensor for the tank)
 – 1 x Pump outlet joint connector
 – 1 x Splice kit for cable join
 – 1 x Splice kit for waterproof
What You Need To Get By Yourself (Package DO NOT Include):
  – Suitable solar panels. There’re some suggestions in the instruction book.
 – A stainless steel wire ( called safety cable) to hold the pump in the bore. If pumping water from dam or river, a float set up required.
 – A poly pipe from pump to the water tank.
 – Wire power cable (3 wires plus earth). we recommend cable size at least thicker than the original cable in the pump.
3inch water pump 48v dc motor brushless solar power system home pump
